Main Uses：
This machine is widely used in pharmaceutical, chemical, food and other industries mixing dry powder materials of different weight and size of several different materials can be quickly and evenly mixed.

Features：
Machine using a unique triangle swing, rock principle of rotation and translation, produces an alternating pulse strong campaign to promote the continuous mixed materials, the vortex generated by the energy gradient with change, which can produce excellent mixing. The machine also has a smooth operation, low noise, high load factor, and short mixing time.

Working Principle：
Block organic machine, brake motor frequency spindle, rotary connecting rod and cylinder components. Loading of the cylinder in the drive shaft to make an active move and rock and other parallel motor complex, which makes the material along the shell for circumferential, radial and axial movement of three to the compound in order to achieve the mutual flow of a variety of materials spread , doping, to achieve uniform mixing of high purpose.

Specification	10Type	50Type	100Type	200Type	300Type	400Type	500Type	600Type	800Type	1000Type	1200Type	1500Type
Barrel capacity (L)	10	50	100	200	300	400	500	600	800	1000	1200	1500
Maximum loading capacity (L)	8	40	80	160	240	320	400	480	640	800	950	1200
Maximum loading weight (KG)	5	25	50	100	150	200	250	300	400	500	600	750
Spindle speed (r / min)	0-15
Motor Power (kw)	0.55	1.1	1.5	2.2	4	4	5.5	5.5	7.5	7.5	11	15
Dimensions (L × W × H) (mm)	800 ×1200 ×1000	1000 ×1400  ×1200	1200 ×1700  ×1500	1400 ×1800  ×1600	1800 ×1950  ×1800	1800 ×2100 ×1950	1900 ×2000  ×2100	1900 ×2100  ×2250	2200 ×2400  ×2300	2250 ×2600  ×2600	2400 ×2800  ×2800	2500 ×2950  ×3000
Weight (kg)	200	300	500	800	1000	1200	1380	1500	2000	2500	2800	3000
