Main Uses:
This machine is mainly used for grinding animal, plant fiber and chemical fiber materials crushed.

Features:
The machine utilization activities between the tool and the ring gear is relatively high speed, so that the fibers were cut grinding, activities cutter has a coarse broken, the broken and crushed three different micro-tool combination, the product was crushed by the cyclone was finished, been crushed by the bag filter dust recycling.
The machine made of stainless steel bearings and have a water cooling tank crushing; Gear was jagged spiral arc. Continuous discharge.

Technical Parameters:

Model	200	300	400
Capacity (kg / h)	20-100	50-150	80-200
Spindle speed  (r / min)	4500	3800	3400
Feed size (mm)	<5	<5	<5
Fineness of grinding (mm)	80-200	80-200	80-200
Smashing motor (mm)	5.5	7.5	11
Vacuum motor (mm)	0.75	1.1	1.5
Dimensions (mm)	1380×1080×200	1200×1000×2200	1500×1200×2400
